Model:RTFQ350

Automatic Label Slitting Rewinder Machine

Size: 1.2(L)*0.8(W)*1.28(H)m

Customizable: Support width and configuration customizable

Delivery time: 30 working days

Contact Us Watch The Video
RTFQ350 Automatic Label Slitting Rewinder Machine
RTFQ350 Automatic Label Slitting Rewinder Machine
RTFQ350 Automatic Label Slitting Rewinder Machine
RTFQ350 Automatic Label Slitting Rewinder Machine
RTFQ350 Automatic Label Slitting Rewinder Machine
RTFQ350 Automatic Label Slitting Rewinder Machine
RTFQ350 Automatic Label Slitting Rewinder Machine
Description

Unwinding→Web Guiding→Slitting→Rewinding

RTFQ350 automatic label slitting rewinder machine, can be used as a companion machine for die-cutting machines. It is ideal for slitting narrow paper and is equipped with a range of features such as automatic metering, length setting, automatic stop and automatic web guiding.
The machine is compact and takes up little space while still providing excellent performance. It runs at a high speed, ensuring an efficient production process. With its high precision, it guarantees precise slitting results, minimizes waste and improves product quality. Easy operation enables operators of all skill levels to use it, reducing training time and increasing productivity. In addition, it runs stably, minimizing downtime and maintenance costs.






The RTFQ350 automatic label slitting rewinder machine is designed with great attention to detail, with an attractive appearance and user-friendly interface. The compact structure not only saves space, but is also easy to integrate into existing production lines. High-speed operation enables fast turnaround times to meet the needs of high-volume production environments. The accuracy of the slitting process ensures consistent results, while the stability of the machine ensures reliable performance over a long period of time. It is an ideal choice for many industries such as printing, packaging and paper processing.

Main Technical Parameter

Cutting speed

120(m/min)

Max slitting width

350mm

Max unwinding diameter

500mm

Max rewinding diameter

500mm

Min. width after slitting

16mm

Slitting precision

0.10mm

Total power

2kw

Power supply voltage

220V/380V

Overall dimensions

1.2(L)*0.8(W)*1.28(H)m

Machine weight

(about)400kg
